MASTER PIN CONTROL BASIC WITH 10 PINS
Product Details
Brand:
Meisinger
MEISINGER MASTER PIN CONTROL BASIC
Developed with Dr. Istvan Urban
Master-Pin-Control is designed especially for the fixation of resorbable, non-resorbable and titanium reinforced membranes. Since the pins have an extra mini-thread, they are a hybrid between a screw and a pin. The thread increases the surface of the pins and thus offers more stability. In addition, due to the thread and a unique head-design, the pins can be removed easily and safely which is especially important after a successful healing period. With their sharp tip and very stable shank, they can be inserted easily and precisely into dense cortical bone.
Initial Burs
• 186RF-018-RA (x2) Pilot Drill, Spade, Length = 12.0mm, Ext. Ø = 1.8mm, RA
Twist Drills
• 203RF-006-RAL (x2) Length = 7.0mm, Ext. Ø = 0.6mm, RAL
• 203RF-008-RAL (x2) Length = 7.0mm, Ext. Ø = 0.8mm, RAL
Accessories
• MP10 (x10) Length = 3.65mm, Int. Ø = 0.87mm, Ext. Ø = 0.95mm, Head Ø = 2.1mm
• MP11 Handheld Screwdriver
• MP12 Membrane Fixation Pin Holder
• MP14 Membrane Fixation Pin Release
Optionally Available:
• 203S-012-RA Twist Drill, Length = 3.0mm, Ext. Ø = 1.2mm, RA
• MP10 (x10) Refill Pins
• MP50 (x50) Refill Pins
• MP100 (x100) Refill Pins
• MP15 Screwdriver for Tac Removal, Length = 148.0mm
• HI070 Teflon Coated Mallet, Length = 195.0mm
