SCREW SYSTEM TX PROFESSIONAL KIT, BONE FIXATION, 7-16MM SCREWS
Product Details
Brand:
Meisinger
SCREW SYSTEM TX PROFESSIONAL KIT, BONE FIXATION, 7-16MM SCREWS
SKU: BTXPR
The Osteosynthesis System Screw System TX Professional enables the universal use of fixation for autologous bone cylinders, bone blocks and bone shells for the purpose of pre-implantological augmentation. The Torx connection guarantees reliable accommodation of the screws in the driv-ing tool and, at the same time, high tensile forces can be transferred. For each 0.9 mm screw available, the kit contains a larger diameter rescue screw in case the transplant does not allow high tensile fixation. The small diameter and the low head size of the screws allow for a comfortable application for patient and user.
The Screw System TX Professional contains additional screws in the lengths of 13.0 mm and 16.0 mm.
Accessories
• 31053-RAL Screwdriver, Length = 27.0mm, RAL
• HM141F-023-RAL Tungsten Carbide, Round Drill, Ext. Ø = 2.3mm, RAL
Twist Drills
• 203RF-009-RAL Length = 9.0mm, Ext. Ø = 0.9mm, RAL
• 203RF-011-RAL Length = 9.0mm, Ext. Ø = 1.1mm, RAL
• TC203-010-RA Length = 12.0mm, Ext. Ø = 5.0mm, RA
• A2001 Length = 12.0mm, Ext. Ø = 6.0mm, RAL
Screws
• TCT09-007 Length = 7.0mm, Ext. Ø = 1.1mm, Min. Ø = 0.9mm, Head Ø = 2.5mm, RAL
• TCT09-010 Length = 10.0mm, Ext. Ø = 1.1mm, Min. Ø = 0.9mm, Head Ø = 2.5mm, RAL
• TCT09-013 Length = 13.0mm, Ext. Ø = 1.1mm, Min. Ø = 0.9mm, Head Ø = 2.5mm, RAL
• TCT09-016 Length = 16.0mm, Ext. Ø = 1.1mm, Min. Ø = 0.9mm, Head Ø = 2.5mm, RAL
• TCT10-007 Length = 7.0mm, Ext. Ø = 1.3mm, Min. Ø = 1.0mm, Head Ø = 2.5mm, RAL
• TCT10-010 Length = 10.0mm, Ext. Ø = 1.3mm, Min. Ø = 1.0mm, Head Ø = 2.5mm, RAL
• TCT13-007 Length = 13.0mm, Ext. Ø = 1.3mm, Min. Ø = 1.0mm, Head Ø = 2.5mm, RAL
• TCT16-010 Length = 16.0mm, Ext. Ø = 1.3mm, Min. Ø = 1.0mm, Head Ø = 2.5mm, RAL
