SPLIT CONTROL 15MM-HORIZONTAL BONE SPREADING
Product Details
Brand:
Meisinger
SPLIT CONTROL 15MM-HORIZONTAL BONE SPREADING
SKU: CSP15
Split-Control 15 mm is a system for gentle widening of the alveolar ridge and simultaneous lateral bone condensing in the case of a horizontal bone deficit. With the aid of screw-like condensing and spreading instruments (Spreaders), it is possible to achieve a controlled and gentle dilatation of horizontally resorbed bone (Bone Spreading).
Further, cancellous bone is condensed due to the special geometry of the spreaders (Bone Condensing), so that the primary stability of the inserted implants is increased.
Split-Control 15 mm provides an extensive range of instruments for a controlled dilatation with spreaders with a length of 15 mm.
Accessories
• 186RF-018-RA Initial Bur, Pilot Drill, Length = 12.0mm, Ext. Ø = 1.8mm, RA
• 231DC-070-RA Diamond Saw, Length = 0.3mm, Ext. Ø = 7.0mm, RA
• 231DC-130-RA Diamond Saw, Length = 0.3mm, Ext. Ø = 13.0mm, RA
• CARA4 Straight Ratchet, Length = 84.0mm
Expansion Burs
• A1003-023-RAXL Drill, Length = 15.0mm, Min. Ø = 1.03mm, Ext. Ø = 2.3, RAXL
• D1003-030-RAXL Drill, Length = 15.0mm, Min. Ø = 1.75mm, Ext. Ø = 3.0, RAXL
Osteotomy Instruments
• HM254E-012-RAL Special Fluting, Length = 6.0mm, Ext. Ø = 1.2mm, RAL
• HM33IL-010-RAL Tapered Fissure Cross-Cut, Length = 5.5mm, Ext. Ø = 1.0mm, RAL
Pilot Burs
• A1001-010-RAXL Grey & Yellow, Length = 18.0mm, Ext. Ø = 1.0, RAXL
• D1001-018-RAXL Grey & Blue, Length = 18.0mm, Ext. Ø = 1.8, RAXL
Spreaders
• A1005-027 Length = 15.0mm, Min. Ø = 1.43mm, Ext. Ø = 2.7
• B1005-029 Length = 15.0mm, Min. Ø = 1.64mm, Ext. Ø = 2.9
• C1005-031 Length = 15.0mm, Min. Ø = 1.84mm, Ext. Ø = 3.1
• D1005-033 Length = 15.0mm, Min. Ø = 2.05mm, Ext. Ø = 3.3
• E1005-035 Length = 15.0mm, Min. Ø = 2.26mm, Ext. Ø = 3.5
• F1005-040 Length = 15.0mm, Min. Ø = 2.79mm, Ext. Ø = 4.0
Jollying Aids Spreaders
• CA1RB Length = 18.0mm
• CA0RB Length = 25.0mm
• CA8RA RA, Length = 24.0mm
