TREPHINE EJECTION KIT BY DR. FOUAD KHOURY

SKU BTE00
$1,076.20
Save this product for later
Share this product with your friends
TREPHINE EJECTION KIT BY DR. FOUAD KHOURY
Product Details
Brand: Meisinger

TREPHINE EJECTION KIT BY DR. FOUAD KHOURY

SKU: BTE00

The Trephine Ejection Kit was developed together with Prof. Dr. Fouad Khoury. It contains several unique ideas which turn this kit into something special:

Two-part, internally cooled trephines allow for a safe and minimal invasive extraction of local bone cylinders. The inner cooling reliably prevents a damage of the bone tissue due to overheating, while the removable trephine working parts allow for an especially easy sampling of the cut out bone cylinders. Either with the aid of the ejection needle or the ejection instruments, which perfectly match with the diameter of the trephine working parts, the bone cylinders can be pushed out of the trephines. Furthermore, the included pre-drilling trephines allow for a safe application of the trephines. Due to the two-part trephines, the variety of different diameters and the optimal matching of the instruments, the Trephine Ejection Kit offers highest efficiency, flexibility and precision to the user for the extraction of bone cylinders.


Initial Bur Trephines
• 230KH-021-RA Length = 2.0mm, Int. Ø = 2.1mm, Ext. Ø = 3.1mm, RA
• 230KH-025-RA Length = 2.0mm, Int. Ø = 2.5mm, Ext. Ø = 3.5mm, RA
• 230KH-029-RA Length = 2.0mm, Int. Ø = 2.9mm, Ext. Ø = 3.9mm, RA
• 230KH-033-RA Length = 2.0mm, Int. Ø = 3.3mm, Ext. Ø = 4.3mm, RA

Trephine
• 229KH-021-UNM Length = 15.5mm, Int. Ø = 2.1mm, Ext. Ø = 3.1mm, UNM
• 229KH-025-UNM Length = 15.5mm, Int. Ø = 2.5mm, Ext. Ø = 3.5mm, UNM
• 229KH-029-UNM Length = 15.5mm, Int. Ø = 2.9mm, Ext. Ø = 3.9mm, UNM
• 229KH-033-UNM Length = 15.5mm, Int. Ø = 3.3mm, Ext. Ø = 4.3mm, UNM

Accessories
• 229KH-RA Shank, (x4) Length =20.5mm, RA
• ASTKH-021 Ejection Instrument, Length = 22.0mm, Largest Working Part = 2.1mm, Ext. Ø = 5.5mm
• ASTKH-029 Ejection Instrument, Length = 22.0mm, Largest Working Part = 2.9mm, Ext. Ø = 5.5mm
• ASNKH-008 Ejection Instrument, Length = 37.0mm, Largest Working Part = 0.8mm
• ASHKH Ejection Sleeve, Length = 28.0mm, Int. Ø = 5.5mm
• HRKH1 Hand Wheel, Length = 15.5mm
